Manitou MHT 10135 | 2023

Aanvullende opties en accessoires

• AdBlue
• Palletvorken

Bijzonderheden

=== MAIN SPECIFICATIONS ===

Year: 2020

Operating hours: 0 h (new)

Maximum lifting capacity: 13,500 kg

Maximum lifting height: 9.60 m

Maximum outreach: 5.20 m

Drive type: Diesel

Transmission: Hydrostatic (automatic)

Four-wheel drive: Yes (4WD – 4WS)

Steering modes: 2-wheel steer / 4-wheel steer / Crab mode

Stabilizers: No

Cabin: Enclosed (ROPS-FOPS Level 2 certified)

Heated cabin: Yes

Fork length: 1,200 mm × 180 mm × 75 mm

Tyres: 17.5-R25 (rough-terrain)

Engine manufacturer: Yanmar 4TN107FTT-6SMU1

Engine power: 127 kW (173 hp) @ 2,200 rpm

Maximum torque: 805 Nm @ 1,500 rpm

Emission class: Stage V / Tier 4 Final

Operating weight: 19,950 kg (with forks)

Ground clearance: 0.43 m

Wheelbase: 3.37 m

Turning radius (outside wheels): 5.35 m

Maximum travel speed: 35 km/h

Hydraulic system: Load-sensing pump, 172 l/min @ 350 bar

Fuel tank capacity: 315 l (+ 24 l AdBlue®)

CE certification: Yes

=== HIGHLIGHTS ===

Selected from verified and reliable sources with traceable history

CE certified with complete documentation included

Ready for immediate operation and transport

Comprehensive technical documentation available

=== CONDITION ===

Brand-new machine – unused and in factory condition.

Fully inspected and tested by certified professionals.

Available for immediate delivery.

=== LOCATION & DELIVERY ===

Located in Sittard, The Netherlands.

Worldwide delivery available.

Price on request (EXW / excl. VAT).

The Manitou MHT 10135 is a high-capacity telescopic handler designed for heavy-duty industrial and construction operations.

Powered by a Stage V Yanmar engine delivering 173 hp and 805 Nm of torque, this machine offers superior lifting performance up to 13.5 tons and a height of 9.6 m.

Its hydrostatic transmission and four-wheel drive/steering provide smooth maneuverability and optimal stability on rough terrain.

Equipped with a ROPS/FOPS Level 2 cabin featuring Manitou’s JSM joystick control system, the MHT 10135 combines comfort, precision and safety.

All machines from Colle Rental & Sales are CE approved, fully tested and ready for immediate operation.

Spare parts and professional technical support available upon request.

=== DELIVERY ===

Crane loading available on request for smooth and safe transport.

Flexible worldwide shipping options tailored to your destination and logistics needs.

All transport is professionally managed by the Colle Rental & Sales logistics tea

Meer informatie

Algemene informatie

Type: Verreiker

Aandrijving

AdBlue-systeem: Ja

Aandrijving: Wiel

Functioneel

Maximale reikwijdte: 520 cm

CE markering: ja

Staat

Algemene staat: zeer goed

Technische staat: zeer goed

Optische staat: zeer goed

Overige informatie

Vermogen van aanvullende hydraulica: 172 l/min

Emissieklasse: Stage V / Tier IV final

Leveringsvoorwaarden: EXW

Afmetingen (LxBxH) (m): 735025402,99

Productieland: FR

Meer informatie

Neem voor meer informatie contact op met Sales Department Collé Sittard (+31 464 574 100, +31464574100, sales@colle.eu)
