Traub TNL 12-7

Control : Mitsubishi TX-8i

Turning length : 80 mm

____________

Description

Mainspindle

Technology:Belt-driven spindle

Speed:12.000 rpm

Torque:7 Nm

Barcapacity:15 mm

Movement in Z1:75 mm

Workpiececlamping:Collet chuck

Subspindle

Technology:Belt-driven spindle

Speed:12.000 rpm

Torque:7 Nm

Movement in X4/Z4:222/139 mm

Rapid travers in X3/Z4:30 m/min

Workpiececlamping:Collet chuck

Toolcarrier I (X/Y)

Technology:Turret with 6 stations (Complete drive)

Taper:ø25 mm

Tooldrive:8.000 rpm

1,5 kW

2,4 Nm

Movement in X1/Y1:35/37,5 mm

Rapid travers in X1/Y1:15 m/min

Toolcarrier II (X/Z)

Technology:Turret with 6 stations (Complete drive)

Taper:ø25 mm

Tooldrive:8.000 rpm

1,5 kW

2,4 Nm

Movement in X2/Z2:35/37,5 mm

Rapid travers in X2/Z2:15 m/min

Front attachment

Number of stations:4

Taper:ø28 mm

Distance between stations:32 mm

Tooldrive:12.000 rpm

4 kW

7 Nm

Number of driven stations:4

Movement in X3/Z3:222/139 mm

Rapid travers in X3/Z3:30 m/min

Rear attachment

Number of stations:4

Taper:ø28 mm

Distance between stations:32 mm

Movement in X4:39 mm

Rapid travers in X4:15 m/min

Equipment/Accessory

Chipmanagement:Chip conveyor

Coolingmanagement:Coolant pump

Rawmaterialfeed:Bar loader

FMB minimag 3200

Finishedpartremoval:Workpiecehandling (Tube)

Oilmistseparation:Interface mechanical prepared

Toolholder:Misc. static and driven toolholder
